Waterproof Fire Alarm Siren BS-531_1_WP

Sounder with Beacon for Fire Detection Panels

Olympia Electronics
Supplier : Olympia Electronics
Part Number : BS-531_1_WP
Barcode : 5205327021232
Availability : In Stock

This device is Visual Alarm Devices (VAD) for fire detection panels that offer a strong sound output and an optical warning with a beacon. The strong sound and the optical warning beacon cover many square metres. It features two inputs (N1, N2) for the production of two different sounds. This device can co-operate with any fire detection panel (BSR-2104, BSR-2114, BS1632, BS-1634, BS-1636, BS-636).

15.DHL

Next Shipment in:

12
HOURS
:
37
MINUTES
* Order now your parcel will leave our warehouse in less than 24 HOURS * Trace your package anytime via tracking number that we will send you via SMS and email

product details

Technical Specifications

Power Voltage 21-28 V DC
MAXIMUM CONSUMPTION 1.2W
MAXIMUM SOUND OUTPUT 94dB (sound effect 1)
BEACON 1 Power LED
ΤYPE OF APPLICATION ENVIRONMENT Τype B
MOUNTING Wall
COVERAGE (y) 6 m around the siren at an angle of 180°
MOUNTING HEIGHT (x) 2.4m max
COVERAGE VOLUME CODE W-2.4-6
COVERAGE VOLUME 86.4m³ (max)
FLASH RATE 1 Hz (Switchable to 0.5 Hz)
FLASH COLOUR RED
DEGREES OF COVER PROTECTION IP65
PRODUCED IN ACCORDANCE WITH EN 54-3: 2001 +Α1:2002 +Α2:2006, EN 54-23: 2010
OPERATION TEMPERATURE RANGE 0 to 60 C
RELATIVE HUMIDITY Up to 95%
CONSTRUCTION MATERIALS Bayblend FR3010, transparent polycarbonate
EXTERNAL DIMENSIONS 141 x 141 x 100 mm
TYPICAL WEIGHT 240 gr
GUARANTEE 2 years

Installation and Connection

Please read carefully and follow the instructions provided in the user manuals.

Certification

The waterproof sounder with beacon BS-531/1/WP is certified from H.E.E.Q.A.C. Also H.E.E.Q.A.C. controls the production under CPR number:

What to Do in Case of Fire:

Alarm

1: Do not panic; stay calm.

2: Leave the building as quickly as possible. Touch doors to feel if they are hot before opening them. Use an alternate exit if necessary. Crawl along the floor, and do not stop to collect anything.

3: Meet at a pre-arranged meeting place outside the building.

4: Call the fire department form outside the building.

5: Do not go back inside a burning building. Wait for the fire department to arrive.

Note:These guidelines will assist you in the event of a fire, however, to reduce the chance that fires will start, practice fire safety rules and prevent hazardous situations.



Certifications

OLYMPIA ELECTRONICS S.A. is driven by quality and has adopted production and inspection procedures that help to supply the market with products that are in accordance with the European construction prototypes (ΕΝ). During production, the company applies advanced ‘world-class manufacturing' processes, such as lean systems, TPM and 5S which offers significant competitive advantages. Its products carry certificates from various laboratories such as:

  • LPCB: LPBC Cerification is delivered by BRE Group which is an innovative group of researchers, scientists, engineers and technicians who share a common goal – to make the built environment better for all. They generate new knowledge through independent research. This is used to create the products, standards and qualifications that help to ensure buildings, homes and communities are safe, efficient, productive, sustainable and enjoyable places to be.
  • VdS: VdS is an independent institution which has been ensuring safety and trust in the fields of fire protection and security for many decades and develops advanced safety concepts for significant industrial and commercial enterprises, leading manufacturers and system businesses as well as specialist firms and independent specialists.
  • LLOYD'S REGISTER GROUP: LLOYD'S REGISTER GROUP is one of the world’s leading providers of professional services for engineering and technology – improving safety and increasing the performance of critical infrastructures for clients in over 75 countries worldwide.Their product certification services help companies prove that their products are compliant with specified regulations or that they meet LR's standards and rules.
  • H.E.E.Q.A.C: In addition to a Product Testing Laboratory, HEEQAC has been recognized also as a Product Certification Body according to EN ISO 45011. Our capabilities in providing support for product certifications are related to the extensive capabilities in product testing and to the expertise in the entire range of requirements for certifying a product. Our support for product certification may be based on European Directives (CE Mark or Wheelmark) or any requirements of the customer in accordance with global or national standards.
  • EVPU: EVPU is an independent certification body that provide cerification services.The certification involves assessment of the ability of products to meet criteria stated in technical standards for which the Certification body is accredited.
  • BSI: BSI is a business standards company that bring together the collective wisdom of over 11,000 experts to generate best practice for business. And using this knowledge and experience BSI ensures its assessors are trained to deliver leading certification services to their clients.
  • Bureau Veritas: Bureau Veritas is an international group specialized in the inspection, analysis, audit, and certification of products, infrastructure (buildings, industrial sites, equipment, ships, etc.) and management systems in relation to regulatory or voluntary standards.

The company operates a complete management system, IQMS 'oly q', which includes quality management systems, as well as environmental, hygiene and personnel safety management systems. Olympia Electronics S.A. has been certified according to ISO9001, OHSAS 18001, ISO 140001 and, for the second time, has been accredited the European enterprise distinction in the scope of EFQM Levels of Excellence. Additionally, the company holds the bee bronze award of the European Business Ethics Network since 2011.
